Description
Customized Profile Roll Forming Machine is a profiling machine of metal rain gutter sheet. It is a special equipment for continuous rolling and cold-forming on steel sheet. It adopts coiling steel sheet as the raw material, through continuous rolling and cold-forming, the sheets are automatically cut to the size and specification required.
Main Parts of the Customized Profile Roll Forming Machines
Decoiler, guiding system, roll forming system, cutting system, electric controlling system, hydraulic system, supporter
Advantages
1.The roller shaft is supported by guiding column.
2. Double-chain transmission
3. Electric motor driven, with dynamos in every section
4. PLC Brand: Mitsubishi & Siemens
5. Producing speed can reach to 8-9m/min
Lead Time & Delivery
60 days to produce after receiving the down payment.
Payment
30% TT for down payment, the rest of the contract value should be paid by TT before shipment.
Parameters
NO
|
Item
|
Para
|
Remark
|
1
|
Suitable Material
|
Type
|
Color Steel Sheet
|
|
Thickness (mm)
|
0.3 to 0.7
|
|
Yield Strength (Mpa)
|
230 to 300
|
|
(mm)
|
≤1250
|
|
Capacity of Decoiler
|
5T/8T/10T
|
According to Customer
|
2
|
Material of Rollers
|
No.45 Hard Chromeplate
|
|
3
|
Line Speed (m/min)
|
20
|
|
4
|
Roller Shaft Supporting Structure
|
guiding column
|
|
5
|
Electric Control System
|
PLC
|
Brand: Mitsubishi or Siemens
|
6
|
Operation Desk
|
Touch Screen + Button
|
|
Components
No
|
Name
|
Quantity
|
Remarks
|
1
|
Decoiler
|
1set
|
Up to Customer
|
2
|
Main Machine
|
Pre-cutting Device
|
1set
|
Up to Customer
|
Feeding Device
|
1set
|
|
Filming Device
|
1set
|
Up to Customer
|
Roll Forming System
|
1set
|
|
Movable Safety Guard
|
1set
|
Up to Customer
|
Post Cutting Device
|
1set
|
Without Waste
|
Hydraulic System
|
1set
|
|
3
|
Electric Control System
|
1set
|
|
4
|
Supporter/Automatic Stacker
|
1set
|
Up to Customer |
|
